OWSOO 8CH 1080N DVR + 4pcs AHD 720P Outdoor Bullet CCTV Camera PAL System
*Consist of 8CH 1080N AHD DVR + 4*1500TVL 720P AHD waterproof infrared camera for CCTV security system.
*Support 8 channel 1080N/720P analog cameras preview, record, playback, etc.
*Multiple ways to access on the PC and browser via software, which can be downloaded by link on the user manual.
*Support motion detection record.
*No need any complex installation.
Power supply: DC 12V/2A(included)
Operating system: embedded Linux
Monitor quality: VGA,HD
Encode ability: 4*1080N
Decode ability: 4*1080N
Multi-mode: analog: 8*1080N
Audio compression: G.711A
Record mode: manual>alarm>motion detection>timing
Local Playback: 4ch(local input mode)
Search mode: Search by time, calendar, event, channel
Video input: 4ch BNC
Video output: 1ch VGA, 1ch HD
Network interface: RJ45 10M/100M
USB: 2* USB 2.0 ports
HDD: 1*SATA ports (Max 6TB/per)
DVR Size: Approx. 21*20*4.5cm(L*W*H)
DVR Weight: Approx. 456g/1lb
CCTV Camera Specifications:
Power Supply: DC 12V/1A(included)
Image Sensor: 1/4″ CMOS Sensor
Signal System: NTSC (Only suitable in America, Canada and Japan)
Horizontal Resolution: 720P
Effective Pixel: 1280*720
Lens Size: 3.6mm
Infrared lamp: 24pcs infrared lamps
Infrared distance: 15-25m
Min. illumination: Day(0.1Lux),Night(0.01Lux ,IR on)
White Balance: support
Video Output: 1.0vp-p75Ω BNC Connector
Texture of material: Metal
Waterproof Grade: IP66
Work rate: ＜3W
Camera Size: Approx. 6.5*6*16.5cm(L*W*H)
Camera Weight: Approx. 274g/0.6lb
